Hongfa HF46F Series 5VDC Subminiature Intermediate Relay

Hongfa HF46F Series 5VDC Subminiature Intermediate Relay is Sub-miniature Intermediate Power Relay 5A switching capability highly efficient magnetic circuit for high sensitivity

• Brand: Hongfa
• Coil Voltage (DC):5 V
• Contact Arrangement:1 Form A
• Contact Current Rating:5 A
• Termination:PCB
• Rated voltage:250VAC
• Mounting:PCB-THT
• Contact capacity:AgSnO2In2O3
• Insulation standard:Class B
• Coil power:Approx 0.2W
• Dielectric strength (between coil & contacts):4000VAC 1min
• Creepage Distance:5mm
• Coil resistance:125Ohm
• Insulation resistance:1000MOhm
• Max Switching Current (AC):5A
• Electrical Distance:5mm
• Max Switching Voltage (VAC):277VAC
• Max Switching Voltage (VDC):30VDC
• Weight:Aporox. 3g
• Size:20.5x7x15.3mm
